Monel Bolts Manufacturer in India
Unifit Fastener is a trusted monel bolts manufacturer offering high-performance fastening solutions to various industries worldwide. We also deal in the production of high-quality Monel bolts, which are designed to provide a high level of strength, durability and resistance to corrosion. Our bolts are well engineered with high-grade copper-nickel alloys, which means that our bolts are very resistant to sulphuric, hydrochloric, and hydrofluoric acids and are very appropriate in aggressive and marine environments.
We stock all the varieties that include Monel 400 Bolts and Monel K500 Bolts, which are in high demand in offshore engineering, desalination plants, oil and gas refineries, chemical processing plants, and heat exchangers. These bolts offer outstanding performance through resistance to stress corrosion cracking, pitting and creep corrosion, as well as guaranteeing stable performance even in high-temperature and high-pressure duties.
Unifit Fastener provides the Monel bolts of varying sizes, grades, standards, and dimensions to accommodate the varying requirements of an application. All the bolts are produced to high-quality control standards through high-level technology and high-quality raw materials. Our products are tested through destructive tests and non-destructive tests in order to provide dimensional accuracy, mechanical strength and flawless finish.
We are a major manufacturer of Monel bolts, and therefore any damage to our products during transportation is avoided by ensuring safe and eco-friendly packaging. Our well-organised logistics network will ensure that it is delivered in time as well as fully documented. Unifit Fastener is a reliable provider of Monel bolts, Monel 400 bolts, and Monel K500 bolts to critical industries because of its quality and customer satisfaction.
Request QuoteTable of Contents
- What are Monel bolts?
- Monel Bolts Specifications
- Types of Monel Bolts
- Send Your Enquiry
- Stock Range – Monel Bolt Types
- Equivalent Grades of Monel Bolts
- Monel Bolt Standards
- Chemical Composition of Monel Bolts
- Mechanical Properties of Monel Bolts
- Monel Bolts Price List
- Applications & Uses of Monel Bolts
- People Ask About Monel Bolts Manufacturer
What are Monel bolts?
Monel bolts are the alloys of nickel and copper, like Monel 400 and Monel K500. They offer superior resistance to corrosion in aquatic systems, acidic environments and high temperatures, which makes them well suited to marine equipment, offshore platforms, chemical processing systems, and oil and gas industries where the standard steel bolts do not perform. These bolts are of high tensile strength, great mechanical stability and high service life with a natural silver-grey look. Monel bolts can be of different types, i.e., hex bolts, stud bolts or socket head bolts, and are produced in conformity to international standards, e.g., ASTM F467, to ensure good performance even in harsh and highly corrosive operating environments.
Largest Stockholder of Monel Bolts in India, Monel® Alloy K500 Mushroom Head Square Neck Bolts, UNS N05500 Hex Bolts, Competitive Price of Monel Heavy Hex Bolts, JIS NW 400 Flange Bolts, 2.4360, 2.4375 Machine Bolts, Ready Stock of Monel Bolts, 400 Nickel Alloy Foundation Bolts Trader, ANSI B 28.2.4 1M Monel Alloy 400 Bolts Manufacturers in Mumbai, India, UNS N04400 Bolts.
Monel Bolts Specifications
| Category | Details |
|---|---|
| Specification Standard | ASTM F467 / ASME SF467 |
| Size Range | M3 to M56, 3/16″ to 2″, including customized dimensions |
| Available Lengths | 3 mm up to 200 mm |
| Thread Types | UNC, UNF, BSW, BSF, Metric, or as requested |
| Standards Covered | DIN 931, DIN 934, DIN 970, DIN 933 |
| Additional Thread Series | UNEF, UNC, UNS, NPT, NPTF |
| Other International Standards | ISO 4032, ISO 4033, JIS standards |
| American Standards | ANSI, ASME B18.5, ANSI B18.2.4 1M/2M |
| Forms Available | Hex head, fully threaded, machine bolts, round head etc. |
| Raw Material Sources | Tata Steel, JSPL, Mukand Steel, Usha Martin, Dhamm Steel etc. |
| Thread Configuration | ASME B1.1 Unified Threads 2A/3A & Metric B1.13M 6h–6G |
| Certification | Dual certified to ASTM / ASME |
| Dimensional Standards | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threading Method | Rolled or cut threads, horizontal or vertical tapping |
| Mill Test Certificate | EN 10204 3.1 certificate provided |
| Additional Approvals | PED 97/23/EC, AD 2000 W2 certification |
| Manufacturing Methods | Hot forged (M24–M100), cold forged (M2–M24), CNC machining for specials |
| Head Drive Options | Slotted, Phillips, Six-lobe, combo drive etc. |
| Packaging Options | Bulk bags, cartons, pallet packing or customized as required |
| Surface Coatings | PTFE, Teflon, Zinc, Phosphate, Cadmium, HDG, Xylon coating |
| Finishes Available | Self-color, passivated, BZP, HDG, sherardized, nickel plated, black oxide etc. |
Types of Monel Bolts
Monel U Bolt
Monel Square Bolt
Monel Machine Bolt
Monel Lag Bolts
Monel J Bolt
Monel Heavy Hex Bolt
Monel Eye Bolt
Monel Countersunk Bolts
Monel Carriage Bolts
Monel Anchor Bolt
Monel Allen Cap Bolt
Send Your Enquiry
Stock Range – Monel Bolt Types
| Product Type | UNS Grade | Werkstoff No. |
|---|---|---|
| Monel Hex Bolts | N04400 / N05500 | 2.4360 / 2.4375 |
| Monel Machine Bolts | N04400 / N05500 | 2.4360 / 2.4375 |
| Monel Eye Bolts | N04400 / N05500 | 2.4360 / 2.4375 |
Equivalent Grades of Monel Bolts
| Standard | Werkstoff | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
| Monel K500 | 2.4375 | N05500 | – | – | – | – | – |
Monel Bolt Standards
| Standard No. | Description |
|---|---|
| DIN 315 | Anchor bolts |
| DIN 439B | Hex jam bolt / machine screw |
| DIN 934 | Finished hex bolt |
| DIN 980V | Prevailing torque hex bolt |
| DIN 985 | Square neck lag bolt |
| DIN 6334 | U-bolt rod |
| DIN 6923 | Hex flange bolt |
Chemical Composition of Monel Bolts
| Element | % Content |
|---|---|
| Nickel (Ni) | 63 min |
| Copper (Cu) | 28–34 |
| Iron (Fe) | 2.5 max |
| Silicon (Si) | 0.5 max |
| Carbon (C) | 0.3 max |
| Sulphur (S) | 0.024 max |
| Manganese (Mn) | 2 max |
Mechanical Properties of Monel Bolts
| Property | Metric | Imperial |
|---|---|---|
| Tensile Strength (annealed) | 517–620 MPa | 75–90 ksi |
| Yield Strength | 172–345 MPa | 25–50 ksi |
| Elastic Modulus | 179 GPa | 26,000 ksi |
| Poisson’s Ratio | 0.32 | 0.32 |
Monel Bolts Ready Stock in India
| Monel Bolts | 400 Monel Bolts |
| Monel K500 Hex Bolts | Monel Alloy UNS N04400 Jam Bolts |
| ANSI B 18.2.4 2M Monel U Bolts | K500 Monel Serrated Flange Bolts |
| ASTM F467 Monel Alloy 400 Eye Bolts | ASTM F467 Monel Alloy K500 Anchor Bolts |
| Monel NA 13 Bolts Supplier | K500 Alloy Spring Bolts |
| Monel K500 Tee Bolts | ASME B18.2.2 Monel Insert Bolts Supplier |
| Monel Alloy Large Hexagon Bolts | Monel N05500 Eye Bolts Dealer |
| Monel 400 Serrated Flange Bolts | F467 Grade K500 Industrial Bolts |
| Monel N04400 J Bolts | UNS N05500 Monel Anchor Bolts |
| K500 Alloy Carriage Bolts | Monel Alloy K500 U Bolts Stockists |
| ASME SF467 Monel Alloy Countersunk Bolts | INOX 2.4375 Monel Alloy Machine Bolts Exporter |
| F467 Grade 400 Hex Head Bolts | ASTM F467 400 Monel Hex Bolts |
| K500 Alloy Eye Bolts | Monel Heavy Hex Bolts |
| K500 Alloy Lag Bolt | Monel K500 Foundation Bolts |
| Monel K500 Mushroom Head Square Neck Bolts | Monel Pin-Lock bolts |
| INOX 2.4360 Castle Bolts Exporter | Monel Mushroom Head Square Neck Hex Lag Bolts |
| ASTM F467 Monel 2.4375 Lug Bolts | Monel NiCu30Fe Bolts |
| NiCu30Fe Monel Hex Machine Screw Bolt | 400 Alloy Monel Heavy Hex Bolts Supplier |
| NiCu30Fe Monel Alloy Metric Hex Bolts Dealer | Monel Hex Lag Bolts Stockist |
| Monel Lag bolts Supplier in Mumbai | Monel Alloy K500 U Bolts Manufacturer in India |
| Monel 2.4375 Reducer U Bolts Dimensions | Monel NA 13 Slotted Bolts |
| Monel 2.4360 Extra Tall Cap Bolt | ASTM F467 K500 Forged Eye Bolts at Best Price |
| Monel Alloy NiCu30Fe Hex Bolts Supplier | Suppliers of K500 Monel Heavy Hex Flat Bolts |
Applications & Uses of Monel Bolts
- Marine Engineering and Shipbuilding
- Offshore Oil and Gas Platforms
- Desalination Plants and Seawater Systems
- Chemical and Petrochemical Industries
- Heat Exchangers, Condensers, and Boilers
- Pumps, Valves, and Pipeline Assemblies
- Power Generation Plants
- Aerospace and Defense Components
- Paper and Pulp Industry
- Pharmaceutical and Food Processing Equipment
Monel Bolts Price List
The price range for Monel Bolts is competitive and cost-effective for bulk as well as small quantity requirements.
To receive the latest price list, stock availability, or a customized quotation, simply use the Request a Quote option and share your requirements.
We maintain a wide inventory of standard Monel bolt types and can supply them at highly economical rates, including ANSI B18.2.4 2M Monel Hex Bolts, Machine Bolts, U-Bolts, Lag Bolts and more.
People Ask About Monel Bolts Manufacturer
What is the difference between Monel 400 Bolts and Monel K500 Bolts?
Monel 400 Bolts offer excellent corrosion resistance and are widely used in marine and chemical environments. Monel K500 Bolts provide significantly higher strength and hardness due to precipitation (age) hardening, making them suitable for high-stress and high-load applications where superior mechanical performance is required.
Where are Monel Bolts commonly used?
Monel Bolts are commonly used in oil & gas refineries, shipbuilding, desalination plants, pump and valve assemblies, heat exchangers, marine equipment, and chemical processing units where resistance to seawater, corrosion, and harsh chemicals is essential.
Do you offer Monel Bolts in custom sizes?
Yes, Unifit Fastener supplies Monel Bolts, Monel 400 Bolts, and Monel K500 Bolts in customized sizes, thread types, coatings, and specifications to meet specific project and industry requirements.
