Titanium Round Bar Suppliers, Manufacturer in India
Unifit Fastener is a leading manufacturer and supplier of high-quality titanium products that have outstanding characteristics, which include good resistance to chlorine ions and other corrosive substances. This is one of the key benefits of a titanium round bar in that it is light, and the weight saved by either the end user or installer is substantial. Titanium has a low density compared to other stainless steels like 304 or 316, which are heavier and denser, resulting in a faster and more effective handling and installation process.
Besides being lightweight, corrosion resistance is another significant fact that makes titanium very preferable to industries. It is almost as strong as aluminum but only 60% more dense, which is the optimal compromise of strength and lightness. Titanium flat bars can be used in high temperatures, but high temperatures above 430°C can cause loss of mechanical strength in pure flat bars.
Titanium is quite ductile and therefore of lower hardness than some of the heat-treated steels, though it is very strong in many industrial uses. Moreover, ASTM B348 Ti Alloy Hex Bars enjoy the advantage of a natural passivation process in the air, which makes them have excellent corrosion resistance, which is equal to that of platinum. This combination of light weight, high strength, and better corrosion resistance is rare in other metals; hence, titanium is an excellent choice for fasteners, bars, and other industrial components.
Request QuoteTable of Contents
- Titanium Round Bar Material Grades
- Specification of Titanium Round Bar
- Types of Titanium Round Bar
- Titanium Bar Chemical Properties
- Mechanical Properties of ASTM B348 Titanium Round Bar
- Send Your Enquiry
- Titanium Round Bar Prices
- Equivalent Grades of Pure Titanium Round Bar
- Cold Drawn Titanium Round Bar Tolerances
- Turned ASTM B348 Titanium Round Bar Tolerances (BS 970-3)
- Precision Titanium ASTM B348 Round Bar Tolerances (BS 970-3)
- Applications & Uses of Titanium Round Bars
- People Ask About Nuts Manufacturer
Titanium Round Bar Material Grades
Titanium Gr1/Gr2 Round Bar
Titanium Gr5/Gr9 Round Bar
Specification of Titanium Round Bar
| Specification | Details / Range |
|---|---|
| Standards | DIN, EN, ASTM, JIS, ASME, BS, AISI |
| Round Bar Size | Diameter: 3 mm – 800 mm |
| Flat Bar Size | Thickness: 2 – 100 mm, Width: 10 – 500 mm |
| Angle Bar Size | 3×20×20 mm – 12×100×100 mm |
| Channel Bar | 80×40 mm – 150×75 mm, Thickness: 5–6 mm |
| Rectangular Bars | Thickness: 3 – 12 mm |
| Billet Size | Diameter: 0.5 – 495 mm |
| Rectangle Size | 33×30 mm – 295×1066 mm |
| Hollow Bar | 32 mm OD ×16 mm ID – 250 mm OD × 200 mm ID |
| Tolerance | H8, H9, H10, H11, H12, H13, K9, K10, K11, K12 or as per client requirements |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, rough turned, bright, polish, grinding, black |
| Surface | Hot rolled pickled, bright, sand-blasted, cold drawn, hairline, polished |
| Condition | Hardened & tempered, annealed |
| Technique | Cold drawn, hot rolled, forged round bar, cold rolled, rod |
| Processing | Bar cutting up to 650 mm |
| Form / Profile | Rod, Round, Channel Bar, T-Bar, Flat Bar, Precision Ground Bar, Blocks, Square, Rings, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bar, Ingot, Billet, I/H Bar, Forging |
Send Your Enquiry
Types of Titanium Round Bar
Titanium Round Bar
Titanium Steel Square Bar
Titanium Steel Alloy Rod
Titanium Metal Triangle Bar
Titanium Bright Bar
Titanium Alloy Flat Bar
Titanium Threaded Bar
Ti Metal Accuracy Bar
Pure Titanium Square Bar (Pump Shaft Quality)
CP Titanium Half Round Bar
ASTM B348 Titanium Hex Bar
ASME SB348 Titanium Square Black Bar
Titanium Bar Chemical Properties
| Grade | C (Max) | N (Max) | O (Max) | H (Max) | Ti | Fe (Max) |
|---|---|---|---|---|---|---|
| Gr 1 | 0.08 | 0.03 | 0.18 | 0.015 | Balance | 0.20 |
| Gr 4 | 0.08 | 0.05 | 0.40 | 0.015 | Balance | 0.50 |
| Gr 7 | 0.08 | 0.03 | 0.25 | 0.015 | Balance | 0.30 |
| Gr 9 | 0.08 | 0.03 | 0.15 | 0.015 | – | 0.25 |
| Gr 12 | 0.08 | 0.03 | 0.25 | 0.15 | – | 0.30 |
Mechanical Properties of ASTM B348 Titanium Round Bar
| Grade | Tensile Strength (Ksi / MPa) | Yield Strength (Ksi / MPa) | Elongation (%) | Bend Test |
|---|---|---|---|---|
| 1 | 35 / 240 | 20 / 138 | 45 / 310 | 24 / 1.5T – 2T |
| 2 | 50 / 345 | 40 / 275 | 65 / 450 | 20 / 2T – 2.5T |
| 3 | 65 / 450 | 55 / 380 | 80 / 550 | 18 / 2T – 2.5T |
| 4 | 80 / 550 | 70 / 483 | 95 / 655 | 15 / 2.5T – 3T |
| 5 | 130 / 895 | 120 / 828 | – | 10 / 4.5T – 5T |
| 7 | 50 / 345 | 40 / 275 | 65 / 450 | 20 / 2T – 2.5T |
| 9 | 90 / 620 | 70 / 483 | – | 15 / 2.5T – 3T |
| 12 | 70 / 483 | 50 / 345 | – | 18 / 2T – 2.5T |
Titanium Round Bar Prices
| Description | Price (INR) | Price (USD) | Price (EURO) |
|---|---|---|---|
| Bar Round Titanium Alloy, 6.00 mm | 5,363 | 72.66 | 59.96 |
| Bar Round Titanium Alloy, 10.00 mm | 6,104 | 82.70 | 68.25 |
| Bar Round Titanium Alloy, 12.00 mm | 4,631 | 62.74 | 51.78 |
| Bar Round Titanium Alloy, 14.00 mm | 4,774 | 64.68 | 53.38 |
| Bar Round Titanium Alloy, 16.00 mm | 4,050 | 54.87 | 45.28 |
| Bar Round Titanium Alloy, 18.00 mm | 3,669 | 49.71 | 41.02 |
| Bar Round Titanium Alloy, 20.00 mm | 3,281 | 44.45 | 36.68 |
| Titanium Round Bar 6Al-4V, 4.53 mm Dia x12 R/L (7 Pcs) | 2,453 | 33.23 | 27.43 |
| Standard Titanium Round Bars | 1,832 | 24.82 | 20.48 |
Equivalent Grades of Pure Titanium Round Bar
| Grade | UNS | Grade | UNS |
|---|---|---|---|
| CP Grade 1 | R50350 | CP Grade 2 | R50400 |
| CP Grade 3 | R50550 | CP Grade 4 | R50700 |
| Titanium Grade 6 | R54520 | CP Grade 7 | R52400 |
| Titanium Grade 9 | R56320 | CP Grade 11 | R52252 |
| CP Grade 12 | R53400 | CP Grade 16 | R52402 |
| CP Grade 17 | R52252 | CP Grade 26 | R52404 |
| CP Grade 27 | R52404 | Titanium Grade 28 | R56323 |
| Titanium Grade 29 | R56404 | Ti-10V-2Fe-3Al | R56410 |
| Ti-13V-11Cr-3Al | R58010 | Ti-2.5Cu | – |
| Ti-3Al-8V-6Cr-4Mo-4Zr | – | Ti-4Al-4Mo-2Sn | – |
| Ti-5-2.5Sn ELI | R54521 | Ti-5.8Al-4.0Sn-3.5Zr-0.7Nb-0.5Mo-0.35Si-0.06C | – |
| Ti-5Al-1Sn-1Zr-1V-0.8Mo | – | Ti-5Al-2Zr-2Sn-4Mo-4Cr | R58650 |
| Ti-6Al-2Sn-2Zr-2Mo-2Cr-0.15Si | R56222 | Ti-6Al-2Sn-4Zr-2Mo | R54620 |
| Ti-6Al-2Sn-4Zr-6Mo | R56260 | Ti-6Al-4V | R56400 |
| Ti-6Al-4V ELI | R56407 | Ti-6Al-6V-2Sn | R56620 |
| Ti-6Al-7Nb | R56700 | Ti-7Al-4Mo | R56740 |
| Ti-8Al-1Mo-1V | R54810 | TIMETAL 21S | – |
Cold Drawn Titanium Round Bar Tolerances
| Shape / Section | Size / Diameter (mm) | Permitted Variation (mm) |
|---|---|---|
| Round | ≥6 – ≤18 | +0 / -0.070 |
| >18 – ≤30 | +0 / -0.085 | |
| >30 – ≤50 | +0 / -0.100 | |
| >50 – ≤80 | +0 / -0.120 | |
| >80 – ≤100 | +0 / -0.140 | |
| Flat (thickness) | <18 | +0 / -0.110 |
| >18 – ≤30 | +0 / -0.130 | |
| >30 – ≤50 | +0 / -0.250 | |
| >50 – ≤80 | +0 / -0.350 | |
| Flat (width) | <18 | +0 / -0.110 |
| >18 – ≤30 | +0 / -0.130 | |
| >30 – ≤50 | +0 / -0.160 | |
| >50 – ≤80 | +0 / -0.190 | |
| >80 – ≤100 | +0 / -0.220 | |
| >100 – ≤130 | +0 / -0.350 | |
| >130 – ≤160 | +0 / -1.000 | |
| >160 – ≤320 | +1.000 / -1.000 | |
| Square / Hexagon | ≥6 – ≤18 | +0 / -0.090 |
| >18 – ≤30 | +0 / -0.110 | |
| >30 – ≤50 | +0 / -0.130 | |
| >50 – ≤80 | +0 / -0.160 | |
| >80 – ≤105 | +0 / -0.250 |
Turned ASTM B348 Titanium Round Bar Tolerances (BS 970-3)
| Diameter (mm) | Permitted Variation (mm) |
|---|---|
| ≥6 – ≤18 | +0 / -0.070 |
| >18 – ≤30 | +0 / -0.085 |
| >30 – ≤50 | +0 / -0.100 |
| >50 – ≤80 | +0 / -0.120 |
| >80 – ≤120 | +0 / -0.140 |
| >120 – ≤180 | +0 / -0.160 |
| >180 – ≤250 | +0 / -0.185 |
| >250 – ≤315 | +0 / -0.210 |
| >315 – ≤400 | +0 / -0.230 |
| >400 | +0 / -0.250 |
Precision Titanium ASTM B348 Round Bar Tolerances (BS 970-3)
| Section | Diameter (mm) | Class A (mm) | Class B (mm) | Class C (mm) |
|---|---|---|---|---|
| Round | ≥6 – <75 | 0.05 | 0.025 | 0.013 |
Applications & Uses of Titanium Round Bars
- Chemical Industry – Corrosion-resistant components for handling aggressive chemicals.
- Marine Applications – Components exposed to seawater, resisting chloride-induced corrosion.
- Aerospace & Aviation – Lightweight and strong bars for structural and mechanical parts.
- Medical Equipment – Biocompatible titanium bars for implants and surgical tools.
- Power Generation – High-strength bars for heat exchangers and turbines.
- Industrial Fasteners & Machinery – Durable components for heavy-duty applications.
People Ask About Nuts Manufacturer
What are the main advantages of Titanium Round Bars?
Titanium Round Bars are lightweight, highly corrosion-resistant, and stronger than aluminum, making them ideal for industries requiring durable and easy-to-install components.
Can Titanium Flat Bars be used at high temperatures?
Yes, they can perform effectively at elevated temperatures. However, exposure above 430 °C may reduce their mechanical strength.
How does titanium resist corrosion?
Titanium undergoes atmospheric passivation, forming a protective oxide layer that provides exceptional corrosion resistance, almost comparable to platinum.
What industries use titanium bars?
Titanium bars are widely used in chemical processing, marine, aerospace, medical, and power generation industries due to their strength and corrosion resistance.
