Copper Nickel Round Bar Manufacturer, Supplier & Stockist

Copper nickel, also called cupronickel, is a high-performance alloy that is extensively used due to it being a strong and durable material and also having corrosion resistance. In Unifit Fastener, the copper-nickel round bars are produced with a nickel content of between 10 and 30 per cent in combination with copper and trace metals such as iron and manganese. This fine structure offers great protection against corrosion, erosion, and reducing conditions, and the material can be applied to the marine, offshore, and industrial areas.

Copper nickel round bar are available with a consistent thermal conductivity of about 50 W/mK so that the mechanical performance can be maintained consistently despite varying temperature conditions. The 70 30 Copper Nickel Round Bar that includes 70 per cent of copper and 30 per cent of nickel is particularly useful due to the high level of resistance to seawater corrosion and biofouling. Equally, the 90/10 copper-nickel round bar provides superior ductility, hardness and general corrosion resistance and is thus suitable for piping and heat exchanger systems.

Another product supplied by Unifit Fastener is ASTM B151 UNS C70600 Hex Bars, which have six flat sides that make them easy to handle and easily installed. The CuNi 70/30 Flat Bars are designed with the geometry of a rectangle with great tensile and yield characteristics, whereas 90/10 Cupro Nickel Rods exhibit even strength and stability in carrying loads.

Copper nickel bars sold by Unifit Fastener are made out of high-quality raw materials, state-of-the-art equipment, and quality controls. Individual products are packed in a secure way so that they are delivered safely. Today, call our team to have competitive prices, personal sizes or technical support.

Request Quote

What is Cupro Nickel Round Bar?

A Cupro Nickel Round Bar is a cylindrical metal bar manufactured with a copper alloy with a nickel content (usually 10-30%), with some minor additions of iron and manganese, which is of great importance in the marine hardware, heat exchangers, piping and construction works.

Suppliers and dealers of Cu-Ni Round Bars, Cu-Ni Bright Bars, ASTM B151 Cupro Nickel Round Bars, and Copper Nickel Rods in Mumbai, India. Exporter of Cu-Ni Forged Bars, manufacturer of Cu-Ni Round Bars, Cu-Ni Hex Bars, and Cu-Ni Square Bars across India.

Copper Nickel Round Bar Material Grades

Copper Nickel 90-10 Rod

Copper Nickel 90/10 Rod

Copper Nickel 70-30 Round Bar

Copper Nickel 70/30 Round Bar

Specification of Copper Nickel Round Bar

Parameter Specification
Outside Diameter 10 to 100 mm
Thickness 5 to 500 mm
Length 100 to 3000 mm or as per custom requirement
Surface Finish Bright Polished, Black, Matt Finish, No.4 Finish, Rough Turned, BA Finish
Form / Type Billet, Round, Ingot, Hex (A/F), Square, Rectangle, Forged
Condition Polished, Polished & Cold Drawn, Centreless Ground
UNS C70600 Rod Standards ASTM B151 / ASME SB151
Manufacturing Process Rolled, Forged
Grades ASME SB111 UNS C70600, C70400, C71500, C71000
Testing Eddy Current Test, Pitting Corrosion Test, Radiographic Test, PMI Test
Annealing Temperature 600 – 750°C
Applications (CuNi 90/10 Rods) Condenser Taper Tube Plugs, Seawater Pipework, Offshore Fire Water Systems

Send Your Enquiry

Types Of Copper Nickel Rod

Cupronickel Hex Bar

Cupronickel Hex Bar

Cupro Nickel Bar

Cupro Nickel Bar

Cunifer Rectangular Bar

Cunifer Rectangular Bar

Cuni Alloy Bright Bar

CuNi Alloy Bright Bar

Copper Flat Bar

Copper Flat Bar

ASTM B151 Copper Nickel Square Bar

ASTM B151 Copper Nickel Square Bar

Chemical Composition of Cupronickel Hex Bar

Element Symbol Composition (%)
Copper Cu 89%
Nickel Ni 11%
Iron Fe 2%
Manganese Mn 1%
Lead Pb 1%
Zinc Zn 1%

CuNi Alloy Bright Bar Mechanical Properties

Grade Elongation (%) Density Tensile Strength Melting Point Yield Strength (0.2% Offset)
Cu-Ni 70/30 30% 0.323 lb/in³ at 68°F 50,000 psi 2260°F 20,000 psi
Cu-Ni 90/10 30% 0.323 lb/in³ at 68°F 50,000 psi 2260°F 20,000 psi

Copper Nickel Bar Size Chart

Cupro Nickel Hot Rolled Bar

Product Type Imperial Size Metric Size
Cupro Nickel Square Bar 0.75 to 17.7165 in 20 to 450 mm
Copper Nickel Round Bar 0.75 to 17.7165 in 20 to 450 mm
Cunifer Flat Bar 0.1574 to 0.5 in
0.5905 to 1.3779 in

Copper Nickel Cold Drawn Bar

Product Type Imperial Size Metric Size
Cunifer Flat Bar 4 to 12.7 mm 15 to 35 mm
Cupro Nickel Square Bar 0.25 to 1.25 in 6.35 to 35 mm
Copper Nickel Round Bar 0.25 to 3.5 in 6.35 to 88.9 mm
CuNi Hex Bar 0.25 to 2.75 in 6.35 to 69.85 mm (A/F)

Equivalent Grade Chart of Cu-Ni Alloy Rounds

Standard / Grade UNS Designation Werkstoff Nr.
Copper Nickel 70/30 C71500 2.0882
Copper Nickel 90/10 C70600 2.0872

CuNi Bar Manufacturing Size Range

Size / Bore Range Shape / Product Type
8 to 100 mm Cupro Nickel Round Rods
Up to 20 to 100 mm OD (Max) Copper Nickel Hollow Rods
10 to 60 mm CuNi Square Bars
10 to 60 mm Cunifer Hex Bars
Up to 200 mm Copper Nickel Alloy Billets
Width up to 120 mm, Thickness up to 10 mm Cupronickel Flat Bars
Custom Sizes Cu-Ni Ingots

Copper Nickel Round Bar Tolerance Chart

Permissible Dimensional Variations (in mm)

Round Bars
Diameter Range (mm) Permitted Variation (mm)
≥ 6 to ≤ 18 +0 / –0.070
> 18 to ≤ 30 +0 / –0.085
> 30 to ≤ 50 +0 / –0.100
> 50 to ≤ 80 +0 / –0.120
> 80 to ≤ 100 +0 / –0.140

Copper Nickel Bar Tolerance Chart (All Sections)

Section / Shape Size Range (mm) Measurement Basis Permitted Variation (mm)
Round Bar ≥ 6 to ≤ 18 Diameter +0 / –0.070
Round Bar > 18 to ≤ 30 Diameter +0 / –0.085
Round Bar > 30 to ≤ 50 Diameter +0 / –0.100
Round Bar > 50 to ≤ 80 Diameter +0 / –0.120
Round Bar > 80 to ≤ 100 Diameter +0 / –0.140
Square / Hex Bar ≥ 6 to ≤ 18 Across Flats +0 / –0.090
Square / Hex Bar > 18 to ≤ 30 Across Flats +0 / –0.110
Square / Hex Bar > 30 to ≤ 50 Across Flats +0 / –0.130
Square / Hex Bar > 50 to ≤ 80 Across Flats +0 / –0.160
Square / Hex Bar > 80 to ≤ 105 Across Flats +0 / –0.250
Flat Bar < 18 Width +0 / –0.110
Flat Bar > 18 to ≤ 30 Width +0 / –0.130
Flat Bar > 30 to ≤ 50 Width +0 / –0.160
Flat Bar > 50 to ≤ 80 Width +0 / –0.190
Flat Bar > 80 to ≤ 100 Width +0 / –0.220
Flat Bar > 100 to ≤ 130 Width +0 / –0.350
Flat Bar > 130 to ≤ 160 Width +0 / –1.00
Flat Bar > 160 to ≤ 320 Width +1.00 / –1.00
Flat Bar < 18 Thickness +0 / –0.110
Flat Bar > 18 to ≤ 30 Thickness +0 / –0.130
Flat Bar > 30 to ≤ 50 Thickness +0 / –0.250
Flat Bar > 50 to ≤ 80 Thickness +0 / –0.350

Cuni 70/30 Bar Weight Chart (Theoretical Weight in Kg/m)

Flat Bar (L × T mm) Weight (Kg/m) Hex Bar (H mm) Weight (Kg/m) Round Rod (D mm) Weight (Kg/m) Square Bar (C × C mm) Weight (Kg/m)
20 × 10 1.70 12 1.11 10 0.70 10 × 10 0.90
30 × 10 2.67 14 1.51 15 1.58 20 × 20 3.57
40 × 10 3.57 17 2.27 20 2.80 30 × 30 8.05
40 × 20 7.13 19 2.78 25 4.39 40 × 40 14.26
45 × 30 12.05 22 3.73 30 6.32 50 × 50 22.35
50 × 20 8.90 24 4.43 35 8.60 60 × 60 32.25
60 × 20 10.75 27 5.64 40 11.20 70 × 70 43.80
60 × 30 16.13 30 6.97 45 14.20 80 × 80 57.16
60 × 40 21.90 32 7.92 50 17.55 90 × 90 72.44
80 × 20 14.30 36 9.96 55 21.20 100 × 100 89.50
80 × 40 28.57 37 10.77 60 25.30 — —
90 × 30 24.15 38 11.13 65 29.70 — —
90 × 60 48.30 40 12.35 70 34.40 — —
100 × 50 44.75 41 12.98 75 39.40 — —
100 × 70 62.45 42 13.59 80 44.90 — —
120 × 30 32.12 46 16.30 85 50.70 — —
120 × 40 42.82 50 19.36 90 56.90 — —
120 × 60 64.23 55 23.40 95 63.10 — —
120 × 80 85.65 60 27.90 100 69.87 — —

Copper Nickel Round Bar Price List

Size Price (USD) Price (INR)
150.00 mm OD × 0.78 m Length $1,265.86 ₹105,635.45
40 mm × 2 m Length $410.62 ₹34,266.05
1-1/4" × 12" Length $40.81 ₹3,405.58
85.00 mm OD × 0.50 m & Above Length $402.92 ₹33,623.49
120 mm Dia × 1 m Length $2,037.66 ₹170,041.81
65.00 mm OD × 1000 mm Length $420.19 ₹35,064.67
12 mm OD × 6000 mm Length $42.72 ₹3,564.96
60 mm Dia × 1 m Length $513.66 ₹42,864.70

70/30 Copper Nickel Round Bar Size Range

Diameter (inches) Weight per metre (kg) Diameter (inches) Weight per metre (kg)
3" 36.00 6 1/2" 172.00
3 1/4" 42.90 7" 199.00
3 1/2" 49.80 7 1/2" 229.00
3 3/4" 57.10 8" 260.00
4" 65.00 8 1/2" 294.00
4 1/4" 73.40 9" 329.00
4 1/2" 82.30 10" 406.00
5" 102.00 11" 492.00
5 1/4" 111.98 12" 585.00
5 1/2" 123.00 340 mm 728.00
5 3/4" 134.00 16" 1,040.00
6" 146.00 — —

Size Range of CuNi 70/30 Flat Bar

Size (mm) Weight per metre (kg) Size (mm) Weight per metre (kg)
12 × 3 0.28 50 × 6 2.37
20 × 3 0.47 60 × 6 2.84
25 × 3 0.59 75 × 6 3.56
30 × 3 0.71 100 × 6 4.74
40 × 3 0.95 25 × 8 1.58
50 × 3 1.19 30 × 8 1.90
60 × 3 1.42 40 × 8 2.53
75 × 3 1.78 50 × 8 3.16
100 × 3 2.37 60 × 8 3.79
12 × 5 0.47 75 × 8 4.74
20 × 5 0.79 100 × 8 6.32
25 × 5 0.99 25 × 10 1.98
30 × 5 1.19 30 × 10 2.37
40 × 5 1.58 40 × 10 3.16
45 × 5 1.78 50 × 10 3.95
50 × 5 1.98 60 × 10 4.74
60 × 5 2.37 75 × 10 5.93
75 × 5 2.96 100 × 10 7.90
100 × 5 3.95 25 × 12 2.37
12 × 6 0.57 30 × 12 2.84
20 × 6 0.95 40 × 12 3.79
25 × 6 1.19 50 × 12 4.74
30 × 6 1.42 60 × 12 5.69
40 × 6 1.90 75 × 12 7.11
45 × 6 2.13 100 × 12 9.48

Application Of Copper Nickel 90/10 Round Bar

  • Marine hardware
  • Offshore fire water systems
  • Condenser taper tube plugs
  • Sea water pipework
  • Fittings
  • Fasteners
  • Flanges

FAQs About Cupro-Nickel Round Bar Manufacturer

What is a Copper Nickel (Cu-Ni) Bar?

A Copper Nickel Bar is an alloy bar made of copper and nickel, sometimes with small additions of iron, manganese, or other elements, offering excellent corrosion resistance and high strength.

What grades of Cu-Ni Bars are available?

Common grades include Cu-Ni 70/30 and Cu-Ni 90/10, supplied in round, hex, square, and flat forms.

What are the applications of Cu-Ni Bars?

Cu-Ni Bars are widely used in marine, seawater piping, offshore fire water systems, condensers, heat exchangers, and structural applications.

What standards do Cu-Ni Bars comply with?

Our bars comply with ASTM B151 and ASME SB151, ensuring consistent quality and mechanical performance.

Can Cu-Ni Bars be customized in size and shape?

Yes. We supply custom lengths, diameters, and profiles including round, hex, square, and flat bars.
