Nickel Alloy Round Bar Manufacturers in India
Round bars made of nickel are used in both the field of engineering and industries in general, capable of revolutionising the performance of the product. Being a pure metal, nickel is an excellent ductile material, has a high corrosion resistance, and has stable strength at high temperatures. These properties have contributed to the popularity of nickel round bars to be used in harsh operating conditions like chemical processing, power generation and heat-exposed systems.
In Unifit Fastener, nickel round bars are provided on the basis of the ASTM B160 specifications, which include commercially pure nickel grades, including UNS N02200, UNS N02201 (low-carbon nickel) and UNS N02211 (solution-strengthened nickel). These materials are produced in hot-worked, cold-worked or fully annealed forms to suit various needs in terms of application.
Nickel 200 and Nickel 201 round bars have also been characterised by their good formability and can be easily shaped to other profiles. Flexible shapes are available in common shapes: round, square, hexagonal and rectangular bars, which suit the machining and fabrication requirements. These bars are subjected to rigorous tests in order to maintain a consistent quality, such as tensile strength, yield strength, measuring elongation, and examining hardness.
Besides mechanical testing, a full chemical examination is done to ascertain the material composition and adherence to the industry standard. Unifit Fastener has a bias towards producing nickel round bars of high quality, precision, and reliability which meet international standards and are effective in the industrial sector of the small industries where they are utilised.
Request QuoteTable of Contents
- What Are Nickel Alloy Round Bar?
- Nickel Alloy Round Bar Materials
- Specification of Nickel Alloy Round Bar
- Send Your Enquiry
- Types of Nickel Alloy Round Bar
- Stock List of Nickel Rod
- Pure Nickel Alloy Round Bar finishes
- Tolerances for Cold Drawn Nickel Round Bar
- Nickel Round Bar Sizes (Metric, US, ASTM / Canadian, Japanese)
- Nickel Round Bar Weight Chart
- Equivalent Materials of ASTM B160 Nickel Alloy Round Bar
- Mechanical Properties of Nickel Round Bar
- Chemical Composition of Nickel Round Bar
- Pure Nickel Alloy Bright Round Bar Tolerances (ISO "H" Series in mm)
- Nickel Alloy Round Bar Manufacturer in India
- Applications of Nickel Alloy Round Bars
- Nickel Alloy Round Bars Price
- People Ask About Nickel Alloy Round Bar
What Are Nickel Alloy Round Bar?
Nickel Alloy Round Bar is a solid, cylindrically shaped metal rod that is composed of combinations of nickel and other elements (such as chromium, molybdenum, and copper) to form greater strength, toughness, and resistance to heat, corrosion, and oxidation, manifested as superior strength, toughness, and resistance to heat, corrosion, and oxidation compared to the normal metals, thus being essential in aerospace, chemical, marine, and industrial applications where they are unable to resist. These all-purpose bars are cut into different components of high-performance equipment.
Nickel Alloy Round Bar Materials
Monel Round Bar
Inconel/Incoloy Round Bar
Hastelloy Round Bar
Specification of Nickel Alloy Round Bar
| Specification | Details / Range |
|---|---|
| Standards | DIN, EN, ASTM, JIS, ASME, BS, AISI |
| Round Bar Diameter | 3 mm – 800 mm |
| Flat Bar Size | Thickness: 2 – 100 mm Width: 10 – 500 mm |
| Angle Bar Size | 3×20×20 mm – 12×100×100 mm |
| Channel Bars | 80×40 mm – 150×75 mm section Thickness: 5.0 – 6.0 mm |
| Rectangular Bar Thickness | 3.0 – 12.0 mm |
| Billet Size | 1/2 – 495 mm diameter |
| Rectangle Size | 33×30 mm – 295×1066 mm |
| Hollow Bars | 32 mm OD × 16 mm ID – 250 mm OD × 200 mm ID |
| Tolerance | H8, H9, H10, H11, H12, H13, K9, K10, K11, K12 or as per client requirement |
| Surface Finish | Hot rolled pickled, bright, sandblasting, cold drawn, hairline, polished |
| Condition | Annealed, hardened & tempered |
| Technique / Processing | Cold drawn, hot rolled, forged round bars, cold rolled, bars cut up to 650 mm |
| Forms Available | Round, square, rectangular, flat, angle, channel, T-bars, hollow, precision ground bars, blocks, rings, triangle, threaded, hex (A/F), profiles, half-round bars, ingots, billets, I/H bars, forged bars |
Send Your Enquiry
Types of Nickel Alloy Round Bar
Nickel Alloy Round Bar
Nickel Alloy Triangle Bar
Nickel Alloy Threaded Bar
Nickel Alloy T-Bar
Nickel Alloy Square Bar
Nickel Alloy Rounds
Nickel Alloy Rod
Nickel Alloy Rectangular Bar
Nickel Alloy Rebar
Nickel Alloy Precision Ground Stock
Nickel Alloy Precision Ground Bar
Nickel Alloy Hollow Bar
Nickel Alloy Hex Bar
Nickel Alloy Half-Round Bar
Nickel Alloy Flat Bar
Nickel Alloy Hexagonal Bar
Stock List of Nickel Rod
| Item Name | Diameter | Alloy | Density |
|---|---|---|---|
| 1/4 Inch Diameter | 1/4 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 9/32 Inch Diameter | 9/32 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 5/16 Inch Diameter | 5/16 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 11/32 Inch Diameter | 11/32 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 3/8 Inch Diameter | 3/8 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 13/32 Inch Diameter | 13/32 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 7/16 Inch Diameter | 7/16 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 15/32 Inch Diameter | 15/32 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 1/2 Inch Diameter | 1/2 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 17/32 Inch Diameter | 17/32 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 9/16 Inch Diameter | 9/16 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 19/32 Inch Diameter | 19/32 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 5/8 Inch Diameter | 5/8 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
| 21/32 Inch Diameter | 21/32 inches | Alloy 200/201 | 8.89 lbs/in³ (0.321 g/cm³) |
Pure Nickel Alloy Round Bar finishes
| Abbreviation | Finish Description |
|---|---|
| CD | Cold Drawn |
| BD | Bright Drawn |
| CG | Centreless Ground |
| CF | Cold Finished |
| P&T | Peeled & Turned |
| ST | Smooth Turned |
| P | Polished |
| SRE | Slit Rolled Edge |
| HF | Hot Finished |
| HRAP | Hot Rolled Annealed & Pickled |
| RT | Rough Turned / Peeled |
| PR | Peeled & Reeled |
Tolerances for Cold Drawn Nickel Round Bar
| Shape / Section | Size / Diameter or Width Across Flats (mm) | Permitted Variation (mm) |
|---|---|---|
| Round | ≥6 ≤18 | +0 / -0.070 |
| >18 ≤30 | +0 / -0.085 | |
| >30 ≤50 | +0 / -0.100 | |
| >50 ≤80 | +0 / -0.120 | |
| >80 ≤100 | +0 / -0.140 | |
| Flat (Thickness) | <18 | +0 / -0.110 |
| >18 ≤30 | +0 / -0.130 | |
| >30 ≤50 | +0 / -0.250 | |
| >50 ≤80 | +0 / -0.350 | |
| Flat (Width) | <18 | +0 / -0.110 |
| >18 ≤30 | +0 / -0.130 | |
| >30 ≤50 | +0 / -0.160 | |
| >50 ≤80 | +0 / -0.190 | |
| >80 ≤100 | +0 / -0.220 | |
| >100 ≤130 | +0 / -0.350 | |
| >130 ≤160 | +0 / -1.00 | |
| >160 ≤320 | +1.00 / -1.00 | |
| Square / Hexagon | ≥6 ≤18 | +0 / -0.090 |
| >18 ≤30 | +0 / -0.110 | |
| >30 ≤50 | +0 / -0.130 | |
| >50 ≤80 | +0 / -0.160 | |
| >80 ≤105 | +0 / -0.250 |
Nickel Round Bar Sizes (Metric, US, ASTM / Canadian, Japanese)
| Metric Bar Size (mm) | US Bar Size | Diam. (Inches) | ASTM/Canadian Bar Size | Diam. (mm²) | Japanese Bar Size | Diam. (mm) |
|---|---|---|---|---|---|---|
| 5 | 5 | #2 | 0.250 | 10M | 100 | 6 |
| 5.5 | 5.5 | #3 | 0.375 | 15M | 200 | 10 |
| 6 | 6 | #4 | 0.500 | 20M | 300 | 13 |
| 7 | 7 | #5 | 0.625 | 25M | 500 | 16 |
| 8 | 8 | #6 | 0.750 | 30M | 700 | 19 |
| 9 | 9 | #7 | 0.875 | 35M | 1000 | 22 |
| 10 | 10 | #8 | 1.000 | 45M | 1500 | 25 |
| 11 | 11 | #9 | 1.125 | 55M | 2500 | 29 |
| 12 | 12 | #10 | 1.250 | – | – | 32 |
| 14 | 14 | #11 | 1.375 | – | – | 35 |
| 16 | 16 | #12 | 1.500 | – | – | 38 |
| 18 | 18 | #13 | 1.625 | – | – | 41 |
| 20 | 20 | #14 | 1.750 | – | – | 44 |
| 22 | 22 | #15 | 1.875 | – | – | 48 |
| 25 | 25 | #16 | 2.000 | – | – | 51 |
| 28 | 28 | #18 | 2.250 | – | – | 57 |
| 32 | 32 | – | – | – | – | – |
| 36 | 36 | – | – | – | – | – |
| 40 | 40 | – | – | – | – | – |
| 44 | 44 | – | – | – | – | – |
| 50 | 50 | – | – | – | – | – |
Nickel Round Bar Weight Chart
| Size (inches) | Length (inches) | Weight / ft. (lbs) |
|---|---|---|
| 0.500 | 120 / 216 | 0.749 |
| 0.750 | 120 / 216 | 1.686 |
| 0.875 | 120 / 216 | 2.295 |
| 1.250 | 120 / 216 | 4.683 |
| 1.375 | 120 / 216 | 5.666 |
| 1.500 | 120 / 316 | 6.743 |
| 1.750 | 120 / 216 | 9.179 |
| 2.000 | 120 / 216 | 11.988 |
| 2.250 | 120 / 216 | 15.173 |
| 2.500 | 120 / 216 | 18.732 |
| 2.750 | 120 / 216 | 22.665 |
| 2.875 | 120 / 216 | 24.773 |
| 3.000 | 120 / 216 | 26.974 |
| 3.250 | 120 / 216 | 31.657 |
| 3.500 | 120 / 216 | 36.714 |
Equivalent Materials of ASTM B160 Nickel Alloy Round Bar
| Alloy | DN / Trade Name | Material No. | UNS No. | ASTM Specification | DIN Specification |
|---|---|---|---|---|---|
| Nickel 200 | R-Nickel 99.2 | 2.4066 | N02200 | ASTM B160 | DIN 17740 |
| Nickel 201 | NR-Nickel 99 | 2.4068 | N02201 | ASTM B160 | DIN 17740 |
| Ni99.6 | BR-Nickel 99.6 | 2.4060 | – | – | DIN 17740 |
| LC-Ni99.6 | NR-Nickel 99.6 | 2.4061 | – | – | DIN 17740 |
Mechanical Properties of Nickel Round Bar
| Property | Value |
|---|---|
| Density | 8.9 g/cm³ |
| Melting Point | 1446 °C (2635 °F) |
| Tensile Strength | 67,000 psi / 462 MPa |
| Yield Strength (0.2% Offset) | 21,500 psi / 148 MPa |
| Elongation | 45% |
Chemical Composition of Nickel Round Bar
| Grade | Ni | Fe | C | Mn | Si | Cu | Mg | Ti | S |
|---|---|---|---|---|---|---|---|---|---|
| Nickel 201 | 99.0 Min | 0.4 Max | 0.02 Max | 0.35 Max | 0.2 Max | 0.25 Max | 0.15 Max | 0.1 Max | 0.01 Max |
| Nickel 200 | 99.0 Min | 0.4 Max | 0.15 Max | 0.35 Max | 0.1 Max | 0.25 Max | – | – | 0.01 Max |
Pure Nickel Alloy Bright Round Bar Tolerances (ISO "H" Series in mm)
| Nominal Diameter (mm) | h5 | h6 | h7 | h8 | h9 | H10 | H11 | h12 |
|---|---|---|---|---|---|---|---|---|
| ~ to 3 | +0.004 / 0 | +0.006 / 0 | +0.01 / 0 | +0.014 / 0 | +0.025 / 0 | +0.04 / 0 | +0.06 / 0 | +0.1 / 0 |
| over 3 to 6 | +0.005 / 0 | +0.008 / 0 | +0.012 / 0 | +0.018 / 0 | +0.03 / 0 | +0.048 / 0 | +0.075 / 0 | +0.12 / 0 |
| over 6 to 10 | +0.006 / 0 | +0.009 / 0 | +0.015 / 0 | +0.022 / 0 | +0.036 / 0 | +0.058 / 0 | +0.09 / 0 | +0.15 / 0 |
| over 10 to 18 | +0.008 / 0 | +0.011 / 0 | +0.018 / 0 | +0.027 / 0 | +0.043 / 0 | +0.07 / 0 | +0.11 / 0 | +0.18 / 0 |
| over 18 to 30 | +0.009 / 0 | +0.013 / 0 | +0.021 / 0 | +0.033 / 0 | +0.052 / 0 | +0.084 / 0 | +0.13 / 0 | +0.21 / 0 |
| over 30 to 50 | +0.011 / 0 | +0.016 / 0 | +0.025 / 0 | +0.039 / 0 | +0.062 / 0 | +0.1 / 0 | +0.16 / 0 | +0.25 / 0 |
| over 50 to 80 | +0.013 / 0 | +0.019 / 0 | +0.03 / 0 | +0.046 / 0 | +0.074 / 0 | +0.12 / 0 | +0.19 / 0 | +0.3 / 0 |
| over 80 to 120 | +0.015 / 0 | +0.022 / 0 | +0.035 / 0 | +0.054 / 0 | +0.087 / 0 | +0.14 / 0 | +0.22 / 0 | +0.35 / 0 |
| over 120 to 180 | +0.018 / 0 | +0.025 / 0 | +0.04 / 0 | +0.063 / 0 | +0.1 / 0 | +0.16 / 0 | +0.25 / 0 | +0.4 / 0 |
| over 180 to 250 | +0.02 / 0 | +0.029 / 0 | +0.046 / 0 | +0.072 / 0 | +0.115 / 0 | +0.185 / 0 | +0.29 / 0 | +0.46 / 0 |
Nickel Alloy Round Bar Manufacturer in India
| Pure Ni Alloy Rectangular Rod Cold Drawn | Ni Alloy Polished Square Rod |
| Pure Ni Alloy Square Rod | Ni Alloy ASTM B160 Polished Flat Rod |
| Ni Alloy ASTM B160 Rectangular Rod stock | Ni Alloy Polished Rod Stock |
| Ni Alloy Hex Rod Cold Drawn | Ni Alloy ASTM B160 Triangular Rod |
| Astm B160 Ni Alloy Threaded Rod M12 | Ni Alloy ASTM B160 Threaded Rod Stock |
| Ni Alloy Square Rod Bright | Ni Alloy Bright Rod Cold Drawn |
| Ni Alloy Square Rod Annealed | ASTM B160 Ni Alloy Bright Rod Flat |
| Astm B160 Ni Alloy Rectangular Rod Bright | Pure Ni Alloy Bright Rod Hollow |
| Ni Alloy ASTM B160 Threaded Rod M16 | Ni Alloy Threaded Rods |
| Ni Alloy Square Rod Black | Pure Ni Alloy Black Rod |
| Pure Ni Alloy Rectangular Rod Black | Ni Alloy Bright Rod Hex |
| Ni Alloy ASTM B160 Hex Rod Black | Ni Alloy Square Rod |
| Ni Alloy ASTM B160 Rectangular Rod Polished | Pure Ni Alloy Polished Round Rod |
Applications of Nickel Alloy Round Bars
- Chemical & Petrochemical Equipment: Resists corrosion from acids and alkalis.
- Marine & Offshore Structures: Excellent performance in seawater and high-humidity environments.
- Aerospace & Aviation Components: High strength and heat resistance for critical parts.
- Heat Exchangers & Boilers: Maintains mechanical properties at elevated temperatures.
- Medical & Laboratory Equipment: High purity and corrosion resistance.
- Electrical & Electronics: Used for battery components, connectors, and resistors.
Nickel Alloy Round Bars Price
Unifit Fastener offers high-quality Nickel Alloy Round Bars in various grades, including Nickel 200 and Nickel 201, available in multiple diameters, lengths, and finishes. We maintain ready stock of standard sizes and can supply custom dimensions to meet your specific engineering or industrial requirements.
For the latest price list and stock availability, click the Request a Quote button or contact us directly with your specifications. Our team will provide a personalized quote promptly, ensuring competitive pricing and timely delivery for your projects.
Request QuotePeople Ask About Nickel Alloy Round Bar
What is a Nickel Alloy Round Bar?
A Nickel Alloy Round Bar is a cylindrical metal bar made from high-purity nickel, including grades like Nickel 200 and 201, known for corrosion resistance, high strength, and excellent performance at elevated temperatures.
What grades of Nickel Round Bars are available?
We supply Nickel 200 (UNS N02200) and Nickel 201 (UNS N02201) in standard and custom sizes, with finishes like cold drawn, bright drawn, polished, and hot rolled annealed.
What are the typical sizes and shapes?
Diameters range from 3 mm to 800 mm, with lengths up to 316 inches. Available shapes include round, square, hexagonal, flat, rectangular, hollow, and custom profiles.
What industries use Nickel Round Bars?
Nickel round bars are widely used in chemical processing, marine equipment, aerospace, power generation, heat exchangers, and high-temperature engineering applications.
